Products Description
The Automatical CNC Glass Working Center is a new generation machine which is professional for glass deep processing.
It is fully autocomplete from pattern design to product processing. it’s a good
choice for mass production for building glass,furniture glass,decoration glass and bathroom glass. The machine can be used for cutting,drilling,milling,shaped notching,edge grinding and polishing on glass.
Product Parameter
ITEM NO. | BN-T2412 | BN-T2620 | BN-T3016 | BN-T3020 |
Stroke of X.Y.Z-Axis | 2500*1300*260（mm） | 2700*2100*260（mm） | 3100*1700*260（mm） | 3100*2100*260（mm） |
Accuracy of X.Y.Z-Axis |
0.01*0.02*0.01 |
0.01*0.02*0.01 |
0.01*0.02*0.01 |
0.01*0.02*0.01 |
Repeatability of X.Y.Z-Axis |
0.005*0.01*0.005 |
0.005*0.01*0.005 |
0.005*0.01*0.005 |
0.005*0.01*0.005 |
Speed of X.Y-Axis | 35-50(m/min) | 35-50(m/min) | 35-50(m/min) | 35-50(m/min) |
Speed of Z-Axis | 15(m/min) | 15(m/min) | 15(m/min) | 15(m/min) |
Max Size of Glass | 2400*1200(mm） | 2600*2000(mm） | 3000*1600(mm） | 3000*2000(mm） |
Min Size of Glass | 200*200 (mm) | 200*200 (mm) | 200*200 (mm) | 200*200 (mm) |
Glass Thickness | 3-40 (mm) | 3-40 (mm) | 3-40 (mm) | 3-40 (mm) |
Bevel Width | 5-40 | 5-40 | 5-40 | 5-40 |
Inclination Angle of Spindle |
0-90° |
0-90° |
0-90° |
0-90° |
Tool Library（PCS） | 0-10 | 0-10 | 0-10 | 0-10 |
Spindle Speed | 0-10000（r/min） | 0-10000（r/min） | 0-10000（r/min） | 0-10000（r/min） |
Spindle Power | 7.5（kw） | 7.5（kw） | 7.5（kw） | 7.5（kw） |
Biggest Diameter of Grinding Wheel |
160mm |
160mm |
160mm |
160mm |
Total Power of Machine | 16kw | 21kw | 21kw | 25kw |
Voltage | 380v | 380v | 380v | 380v |
Weight | 4200kg | 6450kg | 6400kg | 7500kg |
Machine Size | 4700*2450*2600 （mm） | 5900*3200*2600 （mm） | 6300*2900*2600 （mm） | 6300*3200*2600 （mm） |
Product Feature
It is fully auto-complete from pattern design to product processing. it’s a good choice for mass production for building glass,furniture glass,decoration glass and bathroom glass.
Usage
The machine can be used for cutting,drilling,milling,shaped notching,edge grinding and polishing on glass.
Packing & Delivery
Why choose us?
1.Q:Are you a factory or trading company?
A:We are a factory.
2.Q:Is it OK to print my logo on carton?
A:Yes,Please informe us formally before our production and confirm the design.
3.Q:Do you accept credit card payment?
A:According alibaba regulation,we accept TT/Western Union/MoneyGram.Different payment would have different require of customer.
4.Q:Can I have a sample?
A:Yes, but you should pay the freight.
5.Q:How do you make our business long-term and good relationship?
A:We will always keep the best quality product and the most competive price to ensure our clients the best interests. Also we will regard you as our good friend in life and a reliable partner in business cooperation.
