Product Description
This machine is a special equipment for producing composite rubber type insulating glass, which can complete the heating and rolling process of insulating glass; 2. The main drive of the machine adopts AC motor frequency conversion speed regulation, stepless speed regulation in the range of 0~7m/min; The meter test system is provided to obtain appropriate and accurate dimensions between the upper and lower rollers; 4. The roller bearing bushings in the heating furnace are made of materials with good lubrication and heat resistance, and the other rollers adopt outer spherical bearings, centering Good performance, very convenient maintenance; 5. Temperature automatic control device in the heating furnace to ensure the quality of the insulating glass;
Product Parameter
Model | AGM1500 |
Power voltage | 380V 50Hz |
Total power | 18.75 KW |
Max processing glass size | 2000x1500mm |
Sheet glass thickness | 3-19mm |
Maximum insulated glass thickness | 6-30mm |
Glass carry speed | 1-5m/min |
Overall dimmension | 2700x2000x1200mm |
Weight | 1200KGS |
Product Features
The transmission adopts mechanical stepless speed regulation, according to the actual production free adjustment speed, high efficiency and energy saving; the rubber roller lifting mechanism adopts one way overall adjustment, the lifting is uniform, stable and convenient to adjust; the three pairs of rubber rollers have strong pressing force and ensure the quality of pressing. Automatic temperature control, energy efficient.
Standard
Service support
1.24 hours technical supporting by e-mails.
2.24 hours calling service & online service.
3.Oversea door-to-door service available.
4.User manual and detailed operating video/CD available.
